NSI NSi 3000


Description

Industry Description

Button Flush Mount, On 1-5fc/Off 3-15fc, 9"Leads, 120V, 2000W Tungsten, 1800VA Ballast, 600VA LED

Modified Industry Description

BUTTON FLUSH MOUNT PHOTO CELL 120V 2000W

AD Description

NSI 3000 3000 Button Photocontrol, 120 VAC, 2000 W Tungsten, 1200 VA Ballast, Flush Mount, Lexan

Specifications

Application
Pole Lanterns-Lawn Lighting-Walkways
Brand Name
NSi
Country of Origin
CHN
Enclosure
Lexan Housing
Environmental_Conditions
-40 to 140 deg F Operating Temperature
Frequency_Rating
50/60
Material
Lexan
Mounting
Flush Mount
Mounting_Type
Flush
Operating_Temperature
-40 to + 140 F
Power_Consumption
Under 1 Watt
Sensitivity
1 to 5 FC (ON)/3 to 15 FC (OFF) Ratio
Sensor
Cadmium Sulphide Cell
Size
.375 Flush Mount
Special_Features

  • Averages under 1 W power consumption
  • Cadmium sulphide, conformal coated 1/2 in diameter cell
  • Conformal coated cadmium sulphide photocell resists effects of moisture and airborne contaminants
  • Control housing is weather resistant molded Lexan® with ultrasonically welded seams
  • Delay of up to two minutes to prevent false switching due to light from passing vehicles, lightning and more
  • Flush mounting through 11/16 in hole in post lantern or lighting fixture, 3/8 in NPT, stem 3/4 in long
  • On and Off time delay
  • On fail mode
  • Photocell responds to the light spectrum near to that of a human eye
  • Three color coded, minimum 9 in wire leads, 16 AWG, rated for 105 deg C lead wires
  • Works with screw base CFL

Standard
cULus
Sub_Brand
NSi
Supply_Voltage
120 VAC
Timing_Range
2
Type
Button
Voltage Rating
120
