Siemens Siemens QG320


Description

Industry Description

Siemens Low Voltage Residential Circuit Breakers Miniature Thermal Mag Circuit Breakers - Special App are Circuit Protection Load Center Mains, Feeders, and Miniature Circuit Breakers. Type QG Special Features Switching Neutral ApplicationElectrical Distribution Standard UL 489 Voltage Rating 120/240V Amperage Rating20A Trip Range Thermal Magnetic Number Of Poles 3P

Modified Industry Description

3P 20A 120/240V SWN CB

AD Description

Siemens QG320 Type QG Low Voltage Miniature Residential Molded Case Circuit Breaker, 120/240 VAC, 20 A, 10 kA Interrupt, 3 Poles, Thermal Magnetic Trip

Specifications

Amperage Rating
20
Brand Name
Siemens
Connection
PLUG-IN
Country of Origin
MX
Frame
QG
Interrupt_Rating
10
Number_Of_Poles
3
Phase
3
Special Features

  • 10 kA at 240 VAC interrupt rating
  • 3-wire common trip
  • Long time and instantaneous trip functions
  • Neutral pole of the circuit breaker does not connect to load center bus
  • One side is wired to neutral and the other side to the device
  • Switching neutral
  • Used where all conductors are required to be disconnected
Standard
UL489
Sub_Brand
Siemens
Trip_range
Thermal Magnetic
Trip_Type
Thermal Magnetic
Type
Low Voltage Miniature Residential
Voltage Rating
120/240
Width_2
8.0000
Width_3
25.0000
