EasyHeat EasyHeat C3RC
EasyHeat C3RC
Kirby Risk #: 547852
UPC: 00013627013278, 01362701327
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: EasyHeat
Description
Industry Description
Commercial pipe tracing controls, SPDT, snap action thermostat, 22 Amp, 0 to 150- DEG F/-18 to 56 DEG C, 6 DEG diff., 10 ft capillary, Nema 3R enclosure
Modified Industry Description
THERMOSTAT
AD Description
EasyHeat® C3RC Double Throw Thermostat, 4.64 in H x 4.08 in W x 3.3 in D Outside, 22 A, 1 Poles
Vendor Description
The C3RC thermostat is suitable for indoor/outdoor locations and is used with pipe freeze protection, pipe tracing or roof and gutter de-icing heating cable applications. This thermostat has a rainproof, gasketed enclosure that can be used in an ambient-sensing mode (with capillary coiled, as received) or a line sensing mode (with capillary attached to pipe).
Specifications
| Amperage Rating |
22
|
|---|---|
| Application |
Controls for use with pipe freeze protection
|
| Brand Name |
EasyHeat
|
| Country of Origin |
MX
|
| Finish |
Gray
|
| Outside_Depth |
3.3
|
| Outside_Height |
4.64
|
| Outside_Width |
4.08
|
| Poles |
1
|
| Special Features |
Suitable for indoor or outdoor use, rainproof, gasketed enclosure that can be used in ambient-sensing mode, Single Pole Double Throw, Weight 2.7 LBS
|
| Standard |
UL Listed
|
| Sub_Brand |
EasyHeat
|
| Thermostat_Type |
Snap Action
|
| Type |
Double Throw
|
