Hubbell Hubbell HBL63CM70
Hubbell HBL63CM70
Kirby Risk #: 500303
UPC: 78358580875, 783585808758, 00783585808758
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Hubbell
Description
Industry Description
Hubbell Wiring Device Kellems, Locking Devices, TwistLock, Marine Grade,Receptacle, 50A 125V, 2-Pole 3-Wire Grounding, Non-NEMA, Screw Terminal,Galvanized
Modified Industry Description
50A 125V RECPT MARINE
AD Description
Wiring Device-Kellems Twist-Lock® HBL63CM70 Corrosion Resistant Flush Grounding Single Standard Locking Receptacle With Heat Resistant Thermoset Base, 125 VAC, 50 A, 2 Poles, 3 Wires, Yellow
Specifications
| Amperage Rating |
50
|
|---|---|
| Application |
Marine Wiring Devices
|
| Brand Name |
Hubbell
|
| Color |
Yellow
|
| Connection |
Screw Terminals
|
| Conductor Size |
#6 AWG
|
| Country of Origin |
US
|
| Environmental_Conditions |
Indoor Dry unless Protected by Additional Means
|
| Material |
Thermoplastic/Composite
|
| Mounting |
Screw Mount
|
| NEMA_Rating |
Non-NEMA
|
| Number_Of_Poles |
2
|
| Number_Of_Wires |
3
|
| Phase |
1
|
| Size |
Standard Sized Product
|
| Special Features |
Corrosion Resistant
|
| Standard |
UL 498
|
| Sub_Brand |
Hubbell Wiring Device-Kellems
|
| Type |
Single Receptacle
|
| Voltage Rating |
125
|
| Wattage |
6,250
|
