Bussmann Bussmann JCW-1/2E

Name: Bussmann JCW-1/2E
Brand: Bussmann
SKU: 484832
Price: 1123.86 USD
Availability: InStock

Bussmann JCW-1/2E

Kirby Risk #: 484832

UPC: 05171269400, 051712694001, 00051712694001

Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)

Brand: Bussmann

Description

Industry Description

1/2A 2400V/5500V E-Rated Potential Transformer Fuse

Modified Industry Description

FUSE MED VOLT .5A E RATED

AD Description

Bussmann JCW-1/2E Current Limiting Single Barrel Medium Voltage Fuse, 1/2E A, 2.75/5.5 kV, 60/40 kA, Class E

Amperage Rating	1/2E
Application	Medium Voltage Potential Transformers, Small Medium Voltage Service Transformers, Small Medium Voltage Control Transformers
Brand Name	Bussmann
Connection	Ferrule End X Ferrule End
Country of Origin	MX
Element	Single
Interrupt_Rating	60/40
Package_Quantity	1
Response_Time	300
Size	7.31 In Length
Special Features	Low amp, e-rated medium voltage fuses are general purpose current limiting fuses Physically dimensioned for retrofitting in existing hardware Space saving size The current responsive element shall melt in 300 sec at a rms current within the range of 200% to 240% of the continuous current rating of the fuse, fuse refill or link The E-rating defines the melting time current characteristic of the fuse and permits electrical interchangeability of fuses with the same E-rating These fuses offer a high level of fault current interruption in a self-contained non-venting package which can be mounted indoors or in an enclosure
Standard	Contact factory
Sub_Brand	Cooper Bussmann
Type	Current Limiting Single Barrel
Voltage Rating	2.75/5.5
