Hoffman Hoffman APWK2315NF


Description

Industry Description

Steel, Stainless Steel and Non-Metallic Window Kits, 25.50x17.50x.31, Gray, Steel

Modified Industry Description

WINDOW KIT 23.00X15.00

AD Description

Hoffman APWK2315NF A80SW/A80W Non-Metallic Window Kit, 23 in H x 15 in W, 24.69 in H x 16.69 in W Cut Out, 25.5 in H x 17.5 in W x 0.31 in D, Steel, Medium Gray, Painted

Vendor Description

Steel Window Kits have a heavy gauge cold rolled steel formed frame (cleaned and treated for paint endurance and adhesion), painted ANSI 61 gray. The clear window is made of .25-in. (6mm) impact-resistant polycarbonate material. They are ideal for indoor and outdoor Type 3R, 4 and 12 applicatons.

Specifications

Application
Steel Window Kits are designed to be used on Type 4 and 12 enclosures. Stainless Steel Window Kits are suitable for Type 4, 4X, 12 and 13 enclosures in indoor or outdoor applications where corrosion is a problem. These kits are easily installed by making
Brand Name
Hoffman
Color
Medium Gray
Country of Origin
US
Material
Steel
NEMA_Rating
NEMA 3R/4/12
Series
A80SW/A80W
Size
25.50X17.50X.31 in
Special Features

  • All window kits are easy to install and require a simple rectangular enclosure cut-out
  • The gasket material on all windows is-resistant to oils, cutting fluids and many other liquids
  • The window is a clear acrylic 0.25 in scratch-resistant material
  • Window kits of the same size use the same interchangeable cut-out
Standard
UL 508A Component Recognized, Type 4, 4X (stainless steel version only), 12, 13, File No. E61997, CSA Type 4, 4X (stainless steel version only), 12,13, File No. 42186, NEMA/EEMAC 4, 4X (stainless steel version only), 12, 13, IEC 60529, IP66,
Sub_Brand
Hoffman
Type
Steel and Stainless Steel Window Kits
