Thomas & Betts Thomas & Betts ICS78-1


Description

Industry Description

Aluminum 2-25/32 inch Service Entrance Compression Splice for Wire Range - End A: 1/0 ASCR, 1/0, Yellow, End B: 1/0 Stranded, Yellow, Die: 5/8. For AL to AL and AL to CU Conductors.

Modified Industry Description

INSULATED SERV.ENTR.SLEEVE

AD Description

Blackburn® ICS78-1 Insulated Service Entrance Splice, 1/0 AWG ACSR/Stranded Conductor, Die Code: 5/8, 2-25/32 in L, Aluminum

Vendor Description

Blackburn® stands for quality and reliability as a supplier of materials to connect overhead distribution power lines and equipment.

Specifications

Application
For Standard Conductors.
Brand Name
Thomas & Betts
Color
Yellow
Conductor Range
Wire Range - End A: 1/0 ASCR, 1/0, Yellow, End B: 1/0 Stranded, Yellow
Connection
Crimp/ Compression
Conductor Size
1/0
Country of Origin
MX
Environmental_Conditions
All Seasons / Conditions
Insulation
True
Material
Aluminum
Mounting
None
Special Features

  • 1/0 AWG ACSR, 1/0 AWG stranded end A and 1/0 AWG stranded end B conductor
  • 5/8 in die series, U-BG B58CS hydraulic dies, 5/8 (OD58 tool) peach, BG, W-BG, G, TU mechanical dies
  • All seasons environmental conditions
  • All splices are Color coded and marked with strip lengths, installation die codes and compression locations providing easy identification for easy installation
  • Complies with ANSI C119.4 when properly installed on aluminum-to-aluminum or aluminum-to-copper conductors
  • Constructed from aluminum for high conductivity
  • Prefilled with oxide-inhibitor to prevent oxidation and keep out moisture
  • Solid center barriers and large chamfers for easy cable insertion
  • Splices have colored end caps to make identification easy
  • Tough stabilized nylon sleeves resist installing tool pressure and provide reliable 600 VAC insulation
Standard
RUS Accepted. Complies with ANSI C119.4 when properly installed on Aluminum-to-Aluminum or Aluminum-to-Copper Conductors.
Sub_Brand
Blackburn
Type
Insulated
Width_2
10.9000
Width_3
10.9000
