Thomas & Betts Thomas & Betts L70
Thomas & Betts L70
Kirby Risk #: 477245
UPC: 78378613002, 783786130023, 00783786130023, 30783786130024
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Thomas & Betts
Description
Industry Description
Type L - Copper Single Conductor, One-Hole Mount, Socket, Screwdriver Slot Head Screws, Conductor Range 14 Sol-4 Str, Length 1-1/8 Inches, Width 17/32 Inch, Height 35/64 Inch
Modified Industry Description
14 TO 4 AWG COPPER 1 HOLE LUG
AD Description
Blackburn® L70 Type L Compact Mechanical Connector, 14 to 4 AWG Stranded Solid Copper Conductor, 9/32 in Stud, 1 Bolt Holes, Copper
Vendor Description
Blackburn® cast, forged or formed mechanical connections, produced in economical copper and dual-rated aluminum, provide unequaled variety with a large variety of UL and CSA certified solutions for your electrical interface needs.
Specifications
| Brand Name |
Thomas & Betts
|
|---|---|
| Conductor_Range_Main_Primary |
14 - 4
|
| Conductor Size |
14 to 4
|
| Country of Origin |
MX
|
| Insulation |
None
|
| Material |
Copper
|
| Number_Of_Mounting_Holes |
2
|
| Package_Quantity |
100
|
| Poles |
1
|
| Special Features |
|
| Standard |
UL E9809
|
| Stud_Size |
9/32
|
| Sub_Brand |
Blackburn
|
| Type |
Type L Compact
|
