SolaHD SolaHD SVL412100
SolaHD SVL412100
Kirby Risk #: 3172991
UPC: 78347287313, 783472873135, 00783472873135
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: SolaHD
Description
Industry Description
SVL Essential Din Rail Series, Nominal Output Voltage: 12VDC, Nominal Output Current: 4A, Max. Power: 48W, Frequency Rating: 50/63Hz, Single Phase, DIN Rail Mounting
Modified Industry Description
50W SVL ESSENTIAL DIN RAIL SERIES, 12V DC OUT
Specifications
| Amperage Rating |
4
|
|---|---|
| Brand Name |
SolaHD
|
| Cable_Size |
Input Connector size range: 22-12 AWG (0.4-3.4 mm2) for solid conductors; Output Connector size range: 20-12 AWG (0.5-3.4 mm2) for solid conductors
|
| Country of Origin |
TH
|
| Efficiency |
88
|
| Enclosure |
To be installed in an enclosure
|
| Environmental_Conditions |
To be installed in a controlled environment
|
| Frequency_Rating |
50/60
|
| Fuse_Rating |
Internally Fused
|
| Material |
Plastic
|
| Mounting |
Din Rail
|
| Phase |
1
|
| Special Features |
Universal Input; Convection cooling; DC OK LED; NEC Class 2 output; Protection: short circuit, over voltage, overload, over temperature; Two year warranty
|
| Standard |
UL Listed, Industrial Control Equipment for US and Canada: UL 508, CSA C22.2 No. 107.1; UL Recognized Component, ITE for US and Canada: UL 60950-1/CSA C22.2 60950-1 2nd edition; CE: IEC/EN 60950-1 2nd edition CB Scheme, NEC Class 2
|
| Sub_Brand |
SolaHD
|
| Type |
SVL Essential Din Rail Series
|
| Voltage Rating |
12
|
| Wattage |
48
|
