Philips Advance Philips Advance LEDINTA0350C425DOM


Description

Industry Description

Philips Advance, Xitanium, Wattage: 150 Wtt, Voltage Rating: 277 Voltage Rating: 277V, RoHS compliant, UL certified, CSA certified,Environmental standard: UL Damp & Dry

Modified Industry Description

XITANIUM 150W 0.35A 425V 0-10V

AD Description

Advance Xitanium LEDINTA0350C425DOM 2-Wire Dimmable LED Driver, 120 to 277 VAC Input, 120 to 425 VDC Output, 150 W, 9.47 in L x 2.31 in W

Specifications

Amperage Rating
0.35
Application
Outdoor
Country of Origin
USA
Frequency_Rating
50/60
Length1
9.47
Power_Factor
0.9
Power_Rating
150
Special Features

  • 20% total harmonic distortion IEC (maximum)
  • 50 to 60 Hz input frequency
  • F-can bump housing
  • High efficiency for maximum payback
  • High reliability for low maintenance costs
  • Midpack package
  • Surge protection, UL class 1 or class 2
  • These 0 to 10 VDC dimming drivers help address the growing demand for controllability and flexibility allowing the lighting system to be used with various controls to maximum energy savings
  • UL damp and dry environmental standard
Sub_Brand
Philips Advance
Temperature_Rating
-40 to 55
Type
2-Wire Dimmable
Vendor
Signify
Voltage Rating
277
