Hubbell Hubbell GFTWRST20AL


Description

Industry Description

Hubbell Wiring Device Kellems, Power Protection Devices, Receptacle,Weather and Tamper Resistant, Self Test, GFCI, Commercial Grade, 20A125V, 2-Pole 3-Wire Grounding, 5-20R, Almond

Modified Industry Description

20A COM SELF TEST TRWR GFR ALMOND

AD Description

Wiring Device-Kellems GFTWRST20AL 1-Phase Decorator Duplex Heavy Duty Self-Test GFCI Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Almond

Specifications

Amperage Rating
20
Application
Industrial/Comercial
Color
Almond
Connection
Terminal Screws
Conductor Size
#14AWG to #12AWG
Country of Origin
CN
Dimensions
1.75 in W x 1.47 in D
Environmental_Conditions
Indoor Dry Unless Protected by Other Means
Frequency_Rating
60
Horsepower
1
Length1
5.0480
Material
Composite
Mounting
Screw Mount
NEMA_Rating
NEMA 5-20R
Number_Of_Poles
2
Phase
1
Series
Heavy Duty
Size
Standard Sized Product
Special Features

  • 14 to 12 AWG wire
  • Internal back wiring clamp and guide for quick and secure termination
  • Patented AUTOGUARD self-test technology
  • Patented AUTOGUARD® self-test technology includes disconnecting power to the receptacle if critical components are damaged and GFCI protection is lost
  • Patented shutter design for tamper resistant protection
  • Protects against line and load reversal, no power to the face or downstream if device is miswired
  • Triple wipe construction
  • UV and corrosion resistance for harsh and damp applications
Standard
UL498, UL943
Sub_Brand
Hubbell Wiring Device-Kellems
Temperature_Rating
-30 to 150
Type
1-Phase Decorator Duplex Heavy Duty Self-Test
Voltage Rating
125
Wattage
2,500
