Siemens Siemens 6ES73325HB010AB0

Siemens 6ES73325HB010AB0

Kirby Risk #: 3074994

UPC: 25515061267, 66264317796, 00662643177961

Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)

Brand: Siemens

Description

Industry Description

SIMATIC S7-300, ANALOG OUTPUT SM 332, OPTICALLY ISOLATED, 2 AO, U/I 11/12 BITS RESOL., 20 PIN., REMOVE/INSERT WITH ACTIVE BACKPLANE BUS

Modified Industry Description

MODULE OUTPUT S7300 2AO 11/12BITS

AD Description

SIMATIC 6ES73325HB010AB0 PLC Analog Output Module, 2 Outputs, 12 bit Resolution, 0.5% Voltage/0.6% Current Accuracy

Amperage Rating	60 to 135
Application	Optically Isolated
Country of Origin	DE
Dimensions	117 mm L x 40 mm W x 125 mm H
Length1	5.9400
Material	Plastic
Mounting	screw-type mounting
Power_Rating	3
Special Features	0 to 20 mA, -20 to 20 mA, 4 to 20 mA signal range 0.2 ms setting time for resistive load 0.3 ms setting time for capacitive load 12 bit +/-10 V, +/-20 mA, 4 to 20 mA, 1 to 5 VAC: 11 bit + sign, 0 to 10 VAC, 0 mA to 20 mA, 12 bit integration and conversion time/resolution per channel 20 pin front connector 500 VDC isolation voltage
Standard	C-TICK, CE
Sub_Brand	Siemens
Temperature_Rating	0 to 60
Type	Analog Ouput Module
Voltage Rating	24
