Bussmann Bussmann B222-60NFGFWRTR


Description

Industry Description

240V 60AMP NON-FUS DISCON SW PULLOUT

Modified Industry Description

60A NON-FUSIBLE AC DISC W WRTR

AD Description

Bussmann Quik-Spec™ B222-60NFGFWRTR Metallic Non Fusible Pull Out Air Conditioner Disconnect With Weather/Tamper Resistant GFCI, 240 VAC, 60 A, 3 hp at 120 VAC, 10 hp at 240 VAC

Specifications

Amperage Rating
60
Application
Residential, Light Industrial/Commercial A/C and Heat Pump Service, Spas/Whirlpools, Swimming Pools, Pump Houses, Service Entrance Equipment
Connection
14 To 3 AWG (Copper/Aluminum)
Country of Origin
US
Dimensions
13.0000 X 7.5000 X 4.7500
Enclosure
NEMA 3R
Length1
0.0010
Operating_Temperature
75 Deg C
Size
6-1/2 In Width X 4-1/2 In Depth X 11-3/4 In Height
Special Features

  • For added safety, pullout handle can be stored in the compartment in the off position
  • NEMA 3R rainproof enclosures withstand outdoor environment
  • Padlockable with 2-position pullout handle to lock safety shield when in the ON position
Standard
UL 1429, NEC
Sub_Brand
Edison
Type
Non Fusible
Voltage Rating
240
