Bussmann Bussmann A30220507
Bussmann A30220507
Kirby Risk #: 2585109
UPC: 05171234271, 051712342711, 00051712342711
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Bussmann
Description
Industry Description
Single Row Terminal Blocks, 30A, industrial, Black, #6-32 TPI screw, hand wired, Flat base/barrier end, Five-pole, -40 to 105 deg C, Break down voltage 3500V, Standard barrier, 600V, #22 to 12 AWG (Copper), Molded thermoplastic base, zinc p
AD Description
Bussmann A30220507 Standard Barrier Terminal Block Strips & Barrier Block, 600 VAC, Black, 22 to 12 AWG Size
Specifications
| Amperage Rating |
30
|
|---|---|
| Application |
Elec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMs
|
| Color |
Black
|
| Connection |
#6-32 TPI Screw, Hand Wired
|
| Conductor Size |
#22-12 AWG Cu
|
| Country of Origin |
MX
|
| Dimensions |
3.5 in L x 0.65 in W
|
| Length1 |
0.0010
|
| Material |
Molded Thermoplastic
|
| Mounting_Type |
Surface
|
| Special Features |
Break down voltage 3500V
|
| Standard |
UL Listed,CE Marked,RoHS Compliant
|
| Temperature_Rating |
-40 to 105
|
| Type |
Standard Barrier
|
| Voltage Rating |
600
|
