Hoffman Hoffman PTRS482412G4


Description

Industry Description

ProTek Single-Door, UL and NEMA Type 4, 12, 48.54x23.62x11.81, Lt Gray, Steel

Modified Industry Description

PTK SGL DR SD 48X24X12 GRAY

AD Description

Hoffman PROTEK® PTRS482412G4 DWS12 Double Hinged Solid Door Electrical Cabinet, 48.54 in L x 23.62 in W x 11.81 in D, NEMA 4/12//IP66/55 NEMA Rating, Steel

Vendor Description

ProTek Single-Door cabinets are an excellent, off-the-shelf choice for mounting 19-in. rack, panel-mounted devices or other electronic equipment. The cabinets are designed to provide both front and rear access to 19-in. rack-mounted equipment. They provide protection against water, dirt, corrosive agents and other contaminants. ProTek is an excellent choice for applications where space is at a premium and the only option is wall mounting. ProTek comes in a broad range of sizes, materials and configurations to meet many demanding applications.

Specifications

Application
PROTEK Single-Door cabinets are an excellent, off-the-shelf choice for mounting 19-in. rack, panel-mounted devices or other electronic equipment. The cabinets are designed to provide both front and rear access to 19-in. rack-mounted equipment. They provid
Color
Light Gray
Country of Origin
US
Finish
Polyester Powder Paint
Length1
48.54
Material
Steel
Mounting_Type
Wall
NEMA_Rating
NEMA 4/12
Series
DWS12
Special Features

  • All seams are fully welded and ground smooth
  • Doors and body made of 14 ga steel
  • Doors are provided with ground studs to facilitate proper bonding and grounding of the cabinet
  • Key locking wing knob is included on painted steel cabinet, providing access control to the cabinet, two keys are included with each cabinet
  • One set of plated, self-grounding, tapped 10-32 rack angles per EIA universal spacing standards, which can be adjusted front to back, is provided with each center section of the cabinet, additional tapped or square hole rack angles can be added to the cabinet to provide additional mounting
  • Premium seamless, foam in place gasket prevents contaminants from entering the cabinet
  • Rack angles made of plated 12 ga steel
  • Solid door cabinet provides complete physical and visual protection
  • Stainless steel cabinet is provided with a quarter turn slotted latch
  • Stainless steel enclosures made from type 304 stainless steel
  • Wall section welded panel studs which accommodate standard panels
  • Window door, made of scratch-resistant safety glass, provides visual monitoring of internal equipment while maintaining equipment protection
  • Window made of 1/4 in THK, scratch and impact-resistant safety glass
Standard
UL 508A Listed, File Number E61997, cUL Listed per CSA C22.2 No. 94, File Number E61997, Solid Door: Type 4 and 12, Window Door: Type 12, Solid Door, Stainless Steel: Type 4, 4X and 12, NEMA / EEMAC: Type 4, 4X or 12, IEC 60529, IP66 or IP55
Sub_Brand
Hoffman
Type
Double Hinged Solid Door
