Lutron Lutron EC3DT4MWKU1S


Description

Industry Description

EcoSystem 5 percent 3-Wire and EcoSystem Digital Link Controlled T4 Compact, 1 lamp, ballast factor of 0.95, K-can, studded, 26/32W

Modified Industry Description

26/32W 1 BULB T4 BALLAST

AD Description

Lutron® EcoSystem® EC3DT4MWKU1S Type K Digital Dimming Ballast, T4 Quad/CFL/Triple Tube Lamp, 26/32 W, 120/220/240/277 VAC, Programmed Rapid, 0.95 Ballast Factor

Vendor Description

EcoSystem® compact ballasts provide high performance dimming for any compact fluorescent application, including within an EcoSystem® lighting control system. EcoSystem® compact ballasts offer 100 to 5% dimming, providing both energy savings and lighting flexibility.

Specifications

Amperage Rating
0.22
Application
Lighting Control
Ballast_Factor
0.95
Brand Name
Lutron
Color
White
Country of Origin
MX
DIMMABLE
True
Frequency_Rating
50/60
Lamp_Type
T4/CFL
Material
Plastic Metal
Minimum_Starting_Temperature
50
Mounting
Using studs within a fluorescent fixture
Number_Of_Lamps
1
Power_Factor
0.95
Size
4.69 in (119 mm) X 2.94 in (75 mm)
Special Features

  • 100% compatible with all Lutron 3-wire fluorescent controls and EcoSystem® digital controls
  • 100% compatible with all Lutron® 3-wire fluorescent controls and EcoSystem® digital controls
  • 100% performance tested at factory
  • 1710 lumens
  • 3.6 ballast efficacy factor
  • 64.8 lm/W system efficacy
  • Ballast is grounded by the specified terminal or by a mounting screw to the fixture
  • Ballast mounts using two mounting tabs or studs within a fluorescent fixture
  • Compatible with EcoSystem® Energi Savr Node™ unit, Grafik Eye® QS with EcoSystem® unit, PowPak™ dimming module with EcoSystem® unit and Quantum® systems, allowing for integration into an existing/planned EcoSystem® lighting control system
  • Compatible with EcoSystem® energy saver Node unit, GRAFIK Eye® QS with EcoSystem® unit, PowPak™ dimming module with EcoSystem® unit, and Quantum systems, allowing for integration into an existing/planned EcoSystem® lighting control system
  • Continuous, flicker free dimming from 100% to 5%
  • Continuous, flicker-free dimming from 100 to 5%
  • End of lamp life protection circuitry ensures safe operation throughout entire lamp life
  • End-of-lamp-life protection circuitry ensures safe operation throughout entire lamp life
  • Frequency of operation ensures that ballast does not interfere with infrared devices
  • Inrush current limiting circuitry eliminates circuit breaker tripping, switch arcing and relay failure
  • Inrush current limiting circuitry eliminates circuit breaker tripping, switch arcing, and relay failure
  • Lamps turn on to any dimmed level without flashing to full brightness
  • Low harmonic distortion throughout the entire dimming range
  • Non-volatile memory restores all ballast settings after power failure
  • Nonvolatile memory restores all ballast settings after power failure
  • Programmed rapid start design ensures full rated lamp life while dimming and cycling
  • Protected from miswires of any input power to control lead, or from lamp leads to each other and/or ground
  • Supports standard 3-wire line voltage phase control technology
  • Supports standard 3-wire line-voltage phase control technology
  • Ultra quiet operation
  • Ultra-quiet operation
  • Within a fluorescent fixture mounting, K case size
Standard
UL, CSA, FCC Part 18 non consumer
Start_Type
Programmed rapid
Sub_Brand
Lutron
Thermal_Protection
Class P
Total_Harmonic_Distortion
<10%
Type
Dimming Studded
Voltage Rating
120
Wattage
26.4
