Hoffman Hoffman A72R7218FSLP


Description

Industry Description

WeatherPro Outdoor Pad Mount, Type 3R, 72.00x72.00x18.00, Lt Gray, Steel

Modified Industry Description

LARGE 3R PAD MOUNT FREE STAND

AD Description

Hoffman WEATHERPRO™ A72R7218FSLP A3PM 2-Door Pad Mount Enclosure, 72 in L x 72 in W x 18 in D, NEMA 3R/IP32 NEMA Rating, Steel

Vendor Description

WeatherPro Outdoor Pad Mount Enclosures protect controls, drives, power distribution components or contactors in outdoor commercial or industrial power distribution and control applications. The overlapping two-door models with no center post allow full-width access to enclosure interior.

Specifications

Application
WEATHERPRO™ Outdoor Pad Mount Enclosures protect controls, drives, power distribution components or contactors in outdoor commercial or industrial power distribution and control applications. The overlapping two-door models with no center post allow full-
Color
Light Gray
Country of Origin
MX
Finish
Polyester Powder Coated
Length1
72
Material
Steel
Mounting_Type
Free Stand
NEMA_Rating
NEMA 3R/IP32
Series
A3PM
Size
72.00X72.00X18.00 in
Special Features

  • 14 ga galvanized steel
  • 3-point latching system with heavy duty handle
  • Bolted hinges on doors
  • Bonding provision on each door
  • Drip edge overhang on top
  • Louvered overhang with a closure plate
  • Open bottom with pre-punched mounting hole flange
  • Overlapping doors with no center post on two door models
  • Padlock provision in handle
  • Studs included for mounting optional panels on threaded bolts
  • Sturdy 7 ga lifting tabs
  • Welded body construction
Standard
UL 508A Listed, Type 3R, File No. E61997, cUL/CSA C22.2 No. 94 Listed, Type 3R, File No. E61997, NEMA/EEMAC Type 3R, IEC 60529, IP32
Sub_Brand
Hoffman
Type
2-Door
