Lutron Lutron EC3DT418KU2S


Description

Industry Description

EcoSystem 5 percent 3-Wire and EcoSystem Digital Link Controlled T4 Compact, 2 lamps, ballast factor of 0.95, K-can, studded, 18W

Modified Industry Description

18W T4 COMPACT BALLAST, 2 LAMPS

AD Description

Lutron® EcoSystem® EC3DT418KU2S Type K Digital Dimming Ballast, T4 Quad/CFL/Triple Tube Lamp, 18 W, 120/220/240/277 VAC, Programmed Rapid, 0.95 Ballast Factor

Vendor Description

EcoSystem® compact ballasts provide high performance dimming for any compact fluorescent application, including within an EcoSystem® lighting control system. EcoSystem® compact ballasts offer 100 to 5% dimming, providing both energy savings and lighting flexibility.

Specifications

Amperage Rating
0.34/0.18/0.17/0.15
Application
Lighting Control
Ballast_Factor
0.95
Brand Name
Lutron
Color
White
Country of Origin
MX
DIMMABLE
True
Frequency_Rating
60
Lamp_Type
T4
Minimum_Starting_Temperature
10
Mounting
Using 2 mounting tabs within a fluorescent fixture
Number_Of_Lamps
2
Power_Factor
0.95
Size
4.69 in (119 mm) X 9.38 in (239 mm)
Special Features

  • 100% compatible with all Lutron® 3-wire fluorescent controls and EcoSystem® digital controls
  • 100% performance tested at factory
  • Compatible with EcoSystem® Energi Savr Node™ unit, Grafik Eye® QS with EcoSystem® unit, PowPak™ dimming module with EcoSystem® unit and Quantum® systems, allowing for integration into an existing/planned EcoSystem® lighting control system
  • Compatible with energy Savr Node™ with EcoSystem® devices, GRAFIK Eye® QS with EcoSystem® connection, PowPak™ dimming module with EcoSystem® connection and Quantum® systems, allowing for integration into an existing/planned EcoSystem® lighting control system
  • Continuous, flicker free dimming from 100% to 5%
  • Continuous, flicker-free dimming from 100 to 5%
  • End of lamp life protection circuitry ensures safe operation throughout entire lamp life
  • For T4 4-pin quad tube/triple tube
  • Frequency of operation ensures that ballast does not interfere with infrared devices
  • Inrush current limiting circuitry eliminates circuit breaker tripping, switch arcing and relay failure
  • Lamps turn on to any dimmed level without flashing to full brightness
  • Low harmonic distortion throughout the entire dimming range
  • Non-volatile memory restores all ballast settings after power failure
  • Programmed rapid start design ensures full rated lamp life while dimming and cycling
  • Protected from miswires of any input power to control lead or from lamp leads to each other and/or ground
  • Protected from miswires of any input power to control lead, or from lamp leads to each other and/or ground
  • Supports standard 3-wire line voltage phase control technology
  • Ultra quiet operation
  • Ultra-quiet operation
Standard
UL, CSA, FCC Part 18 non consumer
Start_Type
Programmed/Rapid
Sub_Brand
Lutron
Thermal_Protection
Class P
Total_Harmonic_Distortion
<10%
Type
Studded
Voltage Rating
120/220/240/277
Wattage
41.1/39.6/39.4/39.9
