General Cable General Cable E1033S.30.10


Description

Industry Description

Multi-Conductor, Unshielded, Riser NEC Type CMR and/or CL3R, 3C/18 7/26BC UNSH CMR/CL3R

Modified Industry Description

3C/18 7/26BC UNSH CMR/CL3R

AD Description

General Cable® Carol® E1033S.30.10 Type CMR/CL3R Multi-Conductor Unshielded Riser Cable, 300 VAC, (11) 18 AWG Stranded Bare Copper Conductor, 1000 ft Pull-Pac® L

Vendor Description

General Cable® Carol® brand is the right solution for alarm and security wire and cable Carol® offers as broad an offering as anyone in the industry. There are seven basic areas where alarm and security cables are used. General Cable® has the right product to serve every application, including access control, video surveillance/CCTV, component video, lighting control and touch panel systems, fire alarm and life safety, home theater and burglar alarms. Alarm and security cables offer solutions in all major security applications markets, including commercial buildings, residential housing, business and office campus environments, public stadiums and arenas, airport, train, bus and other transportation hubs and schools, colleges and universities.

Specifications

Application
PowerLimited control circuits Wiring of the following systems: Intercom Security Audio Background music Suggested voltage rating: 300 volts
Brand Name
General Cable
Color
Gray
Conductor Material
Copper
Conductor Size
18
Country of Origin
USA
Insulation_Material
S-R PVC
Jacket_Material
PVC
Number Of Conductors
11
Special Features

  • 0.008 in THK nominal insulation
  • 0.015 in THK nominal jacket
  • Bare copper per ASTM B-3, B-8 and B-286
  • Premium grade PVC jacket
  • Premium grade, color coded S-R PVC insulation
  • Sequential footage marked to facilitate installation
Standard
NEC Article 725 Type CL3R (UL: 75°C, 150V) NEC Article 800 Type CMR (UL: 75°C, 300V) RoHS Compliant Directive 2002/95/EC California State Fire Marshall Approved
Sub_Brand
General Cable
Temperature_Rating
-20 to 75
Type
Type CMR/CL3R Multi-Conductor Unshielded
Voltage Rating
300
