Panduit Pan-Net Panduit Pan-Net FLCSSCABL


Description

Industry Description

Pre-Polished Keyed LC Simplex OptiCam OS2 Connector (Keyed A, Black) with 900um Blue boot

Modified Industry Description

LC OPTICAM (KEYED A-BLACK) 9/125

AD Description

Panduit® OptiCam® FLCSSCABL Keyed Pre-Polished Simplex Fiber Optic Connector With 900 um Blue Boot, LC Connector, OS1/OS2 9/125 um Single Mode Fiber, 900 um Buffered, Zirconia Ceramic Ferrule

Specifications

Application
Typical applications for Keyed LCOptiCam® Connectors include maintenance oremergency restoration of secure fiber networksand retrofit/initial install of behind the wall (BTW)connections and the permanent side of interconnectand cross-connect patch fields.
Boot_Color
Blue
Brand Name
Panduit Pan-Net
Color
Black
Connection
NULL
Connector_1_Type
LC
Connector_2_Type
Ceramics
Country of Origin
CRI
Fiber_Size
900µm
Fiber_Type
OS1/OS2
Insertion_Loss
0.3
Special Features

  • Allows up to two re-terminations to achieve optimum termination results, reduces the number of rejected connectors and terminations to provide yield rates approaching 100% for lower installed costs
  • Cable retention boot assemblies consistently provide higher than industry standard cable retention
  • Cam activated fiber and buffer clamp mechanisms provide superior fiber and buffer retention less sensitivity to fiber tensile loading
  • Color specific keys with positive and negative keying features mechanically and visually distinguish connections to prevent unintentional insertion into unlike keyed or non-keyed ports, allow network design flexibility and versatility and accommodate more discrete networks
  • Dual cam design with fiber and buffer clamps secures both the fiber and the buffer during the camming step to facilitate consistent termination results
  • Factory pre-polished fiber endface eliminates time consuming field polishing to reduce installation costs, labor, scrap and the number of tools required
  • Factory pre-polished fiber stub endface eliminates inconsistent and time consuming field polishing to deliver required optical performance
  • Insertion loss 0.3 dB average (multi-mode and single mode)
  • Laser marked to identify fiber stub fiber type (9 um, 62.5, 50 or 50X)
  • Non-optical disconnect design maintains data transmission under tensile loads for jacketed cable
  • OptiCam® termination tool simplifies tooling and termination and virtually eliminates operator error by providing visual indication of proper termination after the cam step has been completed
  • Patented re-termination capability provides yield rates approaching 100%
  • Quick installation provide field termination in less than half the time of field polish connectors
  • Reduces the termination time compared to conventional termination methods
  • Spring loaded senior rear pivot latch LC connector
  • Translucent housing assembly facilitates inspection of the fiber termination quality, resulting in rapid installations, improved termination yields and lower installed costs
  • Universal termination tool with integrated visual termination indicator ensures fast, consistent and optimal terminations of all OptiCam® connectors with connector specific cradles
Standard
RoHS directive is not applicable
Sub_Brand
Panduit
Temperature_Rating
140
Type
Keyed LC Simplex Connectors
Width_2
3.2000
Width_3
4.1000
