Hoffman Hoffman HGF58MDHSS


Description

Industry Description

InterSafe Data Interface Ports for Data Highway Plus Protocol, 143x176x24mm, SS Type 304

Modified Industry Description

8 PIN MINI DH PROG P GF 4X

AD Description

Hoffman INTERSAFE™ HGF58MDHSS A70E Data Interface Port, Highway Plus Protocol Outlet, 120 VAC/8-Pin Mini DIN/DB9F/5 A Circuit Breaker Configuration

Vendor Description

Left hand image shows front view, GFCI receptacle models. Right hand image shows front view, duplex receptacle models. Rear view with and without terminal cover are below the table.

Specifications

Application
Arc Flash Safety; Controls and Drives; Corrosive Environments
Color
Black
Country of Origin
US
Finish
Brushed
Length1
9.2500
Material
Stainless Steel 304
Series
A70E
Size
143X176X24mm
Special Features

  • 120 VAC receptacles and programming connectors are mounted to the plate in 72 standard configurations
  • All standard configurations include a GFCI or standard duplex receptacle with a 5 A circuit breaker for added safety
  • Disk drive enclosure provides access to one or two customer supplied disk drives without opening the cabinet
  • Door gasket between the door and plate assemblies and plate gasket between the plate assembly and the enclosure together provide a tight seal
  • Frame and door assembly with aluminum back plate included with all models
  • Modifications and customization available to accommodate a wide variety of additional connectors
  • Quarter turn latch with screwdriver slot and padlock hasp on all steel and stainless steel door models for convenience and security
  • Ready to use
  • Template provided for accurate enclosure cutout dimensions
Sub_Brand
INTERSAFE
Type
Data Interface Port
