Fluke FLUKE T+PRO


Description

Industry Description

Electrical Tester has all of the advantages of a traditional solenoid tester, with added functionality, but none of the typical drawbacks. With voltage measurement, continuity, built-in flashlight, GFCI trip capability, and the legendary ruggedness and reliability of Fluke, the tester is an excellent choice for most residential, commercial, and industrial applications. The 1AC-II is the pocket-sized voltage detector that can quickly test for energized circuits – a must have for any electrician.

Modified Industry Description

VOLTAGE TESER 600 V AC/DC

AD Description

Fluke® T+PRO 3-Phase Handheld Electrical Tester, (2) AAA Battery, <5 mA Input/6 mA/9 mA/12 mA GFCI Test, 9.99 kOhm, Backlit LCD

Vendor Description

Electrical testers have all the advantages of traditional solenoid testers, with none of the typical drawbacks. Use all 3 voltage detection methods light, sound and vibration, to work more efficiently in noisy environments, dimly lit areas or tight spaces. Built-in flashlight, GFCI trip capability and the legendary ruggedness you expect from Fluke®, make these an excellent choice for most residential, commercial and industrial applications.

Specifications

Accuracy
AC voltage: ± (3 % rdg. + 2 digits); DC voltage: ± (2 % rdg + 2 digits)
Application
Measure voltage
Brand Name
FLUKE
Country of Origin
UKN
Dimensions
7.6 x 2.15 x 1.3
DimensionsInches
7.6 x 2.15 x 1.3
Display
LED Voltage Indication Levels 12 V, 24 V, 48 V, 120 V, 208 V, 240 V, 277 V, 480 V, 600 V; LEDs LEDs turn on between 90 % and 100 % of the indicated voltage on the LED, except for the 12 V LED which turns on between 50 % and 100 %
Enclosure
Hard Plastic
Model
Fluke T+PRO
Operating_Temperature
-10 °C to 55 °C (14 °F to 131 °F)
Package_Quantity
3
Phase
3
Power_Source
(2) AAA Batteries
Resistance_Range
9.99
Special Features

  • +/-(3% Reading + 2 Digits) for AC voltage, +/-(2% Reading + 2 Digits) for DC voltage, +/-(5% Reading + 3 Digits) for resistance LCD accuracy
  • -10 to 55 deg C operating temperature
  • 0.1 VAC for voltages < 50 VAC, 1 VAC for voltages 50 VAC, 0.01 kOhm for resistance LCD resolution
  • 3 forms of AC/DC voltage indication, light, sound and vibration for added user protection and convenience
  • 40 hr battery life
  • 9.99 kOhm resistance
  • Auto-OFF saves battery power 40 hr battery, duty cycle for voltages up to 240 VAC, LEDs turn on at voltages > 30 VAC/VDC +/-35%, 12, 24, 48, 120, 208, 240, 277, 480, 600 VAC LED voltage indication levels, except for the 12 V LED which turns on between 50% and 100%
  • Backlit LCD display for easier viewing
  • Compliant with latest NFPA 70E recommendations
  • Detect live voltage even when the batteries are dead
  • Display hold for easier viewing in hard to test areas
  • Display resolution of 0.1 V, ideal for troubleshooting low voltage lighting
  • Electrical tester offers all the functionality that electricians look for in volt meters and voltage and continuity testers
  • Extra heavy duty, replaceable test leads for more flexibility and durability
  • Hazardous voltage warning light for added user protection
  • ON/off switchable beeper, selectable according to your environment, bright LED flashlight for work in poorly lit areas
  • Replaceable test probes for added flexibility and convenience, convenient probe storage on the back, probe holder for easier testing
  • Rotary field indication, GFCI trip, continuity beeper
  • Safer than traditional solenoid testers and fully compliant with NFPA 70E
  • Test lead strap included for better test lead management
Standard
CAT IV 600 V, CAT III 1000 V rated
Sub_Brand
Fluke
Type
3-Phase Handheld
Voltage Rating
600
