Thomas & Betts Thomas & Betts CPC050


Description

Industry Description

Clamp, One-Piece Cable and Pipe, EMT and Rigid Conduit Trade Size 1/2 Inch, Cable Outer Diameter Range .650-.890 Inches, Steel

Modified Industry Description

1/2IN COBRA (.650-.890) STD.PK.100

AD Description

Superstrut® Cobra® CPC050 700 1-Piece 1-Hole Conduit/Cable Clamp, 1/2 in Conduit, 200 lb Load, 0.65 to 0.89 in OD, Steel

Vendor Description

Superstrut® with a full compliment of fittings, hardware and accessories to complete any metal framing job, is the only system of its kind to provide multiple finishes for total corrosion protection.

Specifications

Application
Attaches a full range of EMT, Rigid conduit and cable to strut channels.
Brand Name
Thomas & Betts
Country of Origin
MUL
Finish
GoldGalv®
Material
Steel
Maximum_Clamp_Diameter
0.890 in
Minimum_Clamp_Diameter
0.650 in
Number_Of_Holes
1
Outside_Diameter
0.65 to 0.89
Special Features

  • 1-piece, heavy duty construction ready-to install right out of the box, no need to break-apart and reassemble, no screws or bolts to drop
  • 2 hooks on the same side make the clamp easy-to install and keep conduits and cable square with strut
  • Heavy duty 5/16 in hex bolt with multi-driver head (Robertson square, Philips® cross-recess and slot) provides a full range of installation options
  • Parallel hook design keeps conduits and cable square with strut
  • Reconfigure wiring without complete disassembly
  • Remove cables easily without disturbing neighboring clamps
  • Rugged stirrup and wide saddle design holds securely with no damage to conduit or cable
  • Works with all depth of strut 13/16 to 3-1/4 in
Standard
UL E160899
Sub_Brand
Superstrut
Thickness
0.112
Type
1-Piece 1-Hole Standard
Width_2
4.7500
