Siemens Siemens HHFD63B175L
Siemens HHFD63B175L
Kirby Risk #: 2004541
UPC: 78364340430, 783643404304, 00783643404304
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Siemens
Description
Industry Description
SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. ASSEMBLED STANDARD 40 DEG C BREAKER FD FRAME WITH EXTRA HIGH BREAKING CAPACITY. 175A 3-POLE (25KAIC AT 600V) (100KAIC AT 480V). INTERCHANGEABLE TRIPUNIT. SPECIAL FEATURES LINE AND LOAD SIDE LUGS (TA1FD350A) WIRE RANGE 6AWG - 350KCMIL (CU) / 4AWG - 350KCMIL (AL). DIMENSIONS (W x H x D) IN 4.50 x 9.5 x 4.00.
AD Description
Sentron™ HHFD63B175L Low Voltage Molded Case Circuit Breaker, 600 VAC, 175 A, 25 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Vendor Description
SiemensSentronSeriesCircuit Breakers have a long history of excellent performance in both the commercial and industrial market segments, they are tried and true in the most critical applications. Siemens SentronSeries circuit breakers are available in nine frame sizes from 125 to 2000 A.
Specifications
| Actuator |
Varying
|
|---|---|
| Amperage Rating |
175
|
| Application |
Standard 40C Breaker
|
| Connection |
Line/Load lugs installed
|
| Country of Origin |
MX
|
| Dimensions |
7 in L x 6 in W x 11 in H
|
| Enclosure |
Varying
|
| Environmental_Conditions |
N/A
|
| Frame |
FD
|
| Frequency_Rating |
50/60
|
| Interrupt_Rating |
25
|
| Length1 |
11.0000
|
| Material |
N/A
|
| Number_Of_Poles |
3
|
| Operating_Temperature |
40C
|
| Phase |
3-Phase
|
| Special Features |
|
| Standard |
HACR
|
| Sub_Brand |
SENTRON
|
| Temperature_Rating |
40
|
| Type |
Low Voltage
|
| Voltage Rating |
600
|
