Thomas & Betts Thomas & Betts CPC300


Description

Industry Description

Clamp, One-Piece Cable and Pipe, EMT and Rigid Conduit Trade Size 3 Inches, Cable Outer Diameter Range 3.060-3.626 Inches, Steel

Modified Industry Description

3 COBRA (3.060 - 3.626) PK.25

AD Description

Superstrut® Cobra® CPC300 700 1-Piece Conduit and Cable Clamp, 3 in Conduit, 350 lb Load, 3.06 to 3.626 in OD, Steel

Vendor Description

Superstrut® with a full compliment of fittings, hardware and accessories to complete any metal framing job, is the only system of its kind to provide multiple finishes for total corrosion protection.

Specifications

Application
Attaches a full range of EMT, Rigid conduit and cable to strut channels.
Brand Name
Thomas & Betts
Conduit_Type
Rigid/EMT
Country of Origin
IN
Finish
Electro-Galvanized/Silver Galvanized
Material
Steel
Maximum_Clamp_Diameter
3.626 in
Minimum_Clamp_Diameter
3.060 in
Number_Of_Holes
0
Outside_Diameter
3.06 to 3.626
Special Features

  • 1-piece, heavy duty construction ready-to install right out of the box, no need to break-apart and reassemble, no screws or bolts to drop
  • 2 hooks on the same side make the clamp easy-to install and keep conduits and cable square with strut
  • Heavy duty 5/16 in hex bolt with multi-driver head (Robertson square, Philips® cross-recess and slot) provides a full range of installation options
  • Parallel hook design keeps conduits and cable square with strut
  • Reconfigure wiring without complete disassembly
  • Remove cables easily without disturbing neighboring clamps
  • Rugged stirrup and wide saddle design holds securely with no damage to conduit or cable
  • Works with all depth of strut 13/16 to 3-1/4 in
Standard
UL E160899
Sub_Brand
Superstrut
Trade_Size
3
Type
1-Piece
Width_2
9.7500
