Siemens Siemens LMD63B600


Description

Industry Description

SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. UN-ASSEMBLED STANDARD 40 DEG C BREAKER LMD FRAME WITH STANDARD BREAKING CAPACITY. 600A 3-POLE (25KAIC AT 600V) (50KAIC AT 480V). INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES LINE AND LOAD SIDE LUGS (TA3K500) WIRE RANGE 1/0AWG - 500KCMIL (CU/AL). DIMENSIONS (W x H x D) IN 7.50 x 16.0 x 4.50.

AD Description

Sentron™ LMD63B600 Mining Circuit Breaker, 600 VAC/500 VDC, 600 A, 25 kA Interrupt, 3 Poles, Thermal Magnetic Trip

Specifications

Actuator
Varying
Amperage Rating
600
Application
Standard 40C Breaker
Connection
N/A
Country of Origin
MX
Dimensions
8 in L x 9 in W x 18 in H
Enclosure
Varying
Environmental_Conditions
N/A
Frame
LM
Frequency_Rating
50 to 60
Interrupt_Rating
25
Length1
18.0000
Material
N/A
Number_Of_Poles
3
Operating_Temperature
40C
Phase
3-Phase
Special_Features

  • 1/0 AWG to 500 kcmil (Cu/Al) wire
  • Varying actuator type

Standard
UL/HACR
Sub_Brand
SENTRON
Temperature_Rating
40
Type
LMD6
Voltage Rating
600 VAC/500 VDC
