SolaHD SolaHD HS19F1B


Description

Industry Description

Buck Boost Transformers, 1.0 KVA, Maximum Secondary Amperage: 83.3 at 12V, 41.6 at 24V, 120 x 240 Volt Primary, 12/24 Volt Secondary

Modified Industry Description

1KVA 120X240-12/24 BB

AD Description

SolaHD HS19F1B Encapsulated Buck Boost Transformer, 120 x 240 VAC Primary, 12/24 VAC Secondary, 1 kVA Power Rating, 50/60 Hz, 1 Phase

Vendor Description

Buck-boost transformers are small, 1-phase, dry-type distribution transformers designed and shipped as insulating/isolating transformers. They have a dual voltage primary and a dual voltage secondary. These transformers can be connected for a wide range of voltage combinations. The most common use is to buck (lower) or boost (raise) the supply voltage a small amount, usually 5 to 27%. Buck-boost transformers are in compliance with NEC article 210.9, exception 1, when field connected as an autotransformer.

Specifications

Boost_Voltage
100-120 , 229-240
Brand Name
SolaHD
Buck_Voltage
132-120 , 264-240
Connection
Conduit Knockouts for side entry to wiring compartment
Country of Origin
US
Enclosure
NEMA 3R, Class 1 Div 2 Group A,B,C and D
Frequency_Rating
50/60
Insulation
UL Class 200°C Insulation System
Maximum_Amperage_Rating
83.3/41.6
Maximum_Input_Current
2.3/4.5
Maximum_Output_Current
9.1/4.5
Number_Of_Channels
190/200/208/220/380/400/415/440 Volt Primary,110/220 Volt Secondary; 200/208/230/400/415/460 Volt Primary, 115/230 Volt Secondary; 208/240/415/480 Volt Primary, 120/240 Volt Secondary (60 Hz Only)
Phase
1
Power_Rating
1
Primary_Voltage
120/240
Secondary_Voltage
12/24
Special Features

  • 500 to 45 kVA units are capsulated with electrical grade silica and epoxy for industrial applications
  • A buck-boost transformer is the ideal solution for changing line voltage by small amounts
  • Electrostatically shielded for quality power on sizes 1 kVA and larger
  • Low cost, compact size and lightweight
  • Rolled steel enclosure
  • They are more efficient and cost less than equivalent isolation transformers
  • They can handle loads up to 20 times the nameplate rating
  • UL listed/NEMA type 3R encapsulated enclosure for indoor and outdoor service
Standard
cULus Listed: E25872, E77014, UL 1561 or UL 506, CSA C22.2 No. 47 or No. 66
Sub_Brand
SolaHD
Type
Encapsulated
Wattage
1,000
