Panduit Pan-Net Panduit Pan-Net CJ5E88TGR
Panduit Pan-Net CJ5E88TGR
Kirby Risk #: 1854641
UPC: 00074983771417, 50074983771412, 074983771417, 07498377141
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Panduit Pan-Net
Description
Industry Description
Category 5e, RJ45, 8-position, 8-wire universal jack module. Green.
Modified Industry Description
CAT 5E RED MINI COM MODULE
AD Description
Panduit® CJ5E88TGR 8-Position 8-Wire Cat 5e Standard Universal Shuttered Jack Module, UTP Module, 1 Port, Plastic, Red
Vendor Description
Category 5e/class D, 8-position, UTP jack module shall terminate 4-pair, 22 to 26 AWG, 100 Ohm unshielded twisted pair cable and shall not require use of a punchdown tool. UTP jack modules shall use a forward motion termination method to optimize performance by maintaining cable pair geometry while eliminating conductor untwist. The termination cap shall be color coded red to designate category 5e performance and shall include a universal label coded for T568A and T568B wiring schemes.
Specifications
| Application |
Unshielded
|
|---|---|
| Brand Name |
Panduit Pan-Net
|
| Cable_Entry |
T568A/T568B
|
| Color |
Red
|
| Country of Origin |
USA
|
| Material |
Plastic
|
| Model |
Bus (jack)
|
| Number_Of_Ports |
1
|
| Slot_Capacity |
1
|
| Standard |
Exceeds Channel and Component Requirements of ANSI/TIA-568.2-D and ISO 11801 Standards for the Respective Category, Meets IEC 60603-7, Supports 2500 Connection Cycles with IEEE 802.3af / 802.3at and 802.3bt Type 3 and Type 4, UL 1863 and UL 2043 and RoHS
|
| Sub_Brand |
Panduit
|
| Type |
8-Position 8-Wire Cat 5e Standard Universal
|
| Width_2 |
7.1500
|
| Width_3 |
7.4000
|
