NSI NSi PT4
NSI PT4
Kirby Risk #: 1854320
UPC: 00662381033017, 662381033017, 66238103301
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: NSI
Description
Industry Description
Stranded Bi-Metallic Pin Terminal 4 AWG Stranded Bi-Metallic Pin Terminals is designed to facilitate termination of aluminum conductors. Tin-plated stranded copper pin. Connector bores are coated with oxide inhibitor. Supplied with EPDM insulating cover. UL 486B listed. Rated 600 volts.
Modified Industry Description
#4 PIN TERMINAL
AD Description
NSI PT4 Bi-Metallic Pin Terminal With Plastisol Insulating Cover, 6 to 4 AWG Conductor, 0.188 in Dia x 0.913 in L Pin, Aluminum, Tan
Specifications
| Application |
Terminate, Splice, Tap Power Connectors
|
|---|---|
| Color |
Tan
|
| Connection |
# 6 Pin
|
| Finish |
Aluminum
|
| Insulation |
Plastisol Cover
|
| Material |
Aluminum - Tin Plated Copper Pin
|
| Size |
L=2.45 - OD=.630 - ID=.236 - Pin Dia=.188
|
| Standard |
UL486
|
| Type |
Bi-Metallic Pin
|
