Thomas & Betts Thomas & Betts KL45-1


Description

Industry Description

Aluminum 3-1/2 Inch Service Entrance Compression Splice for Wire Range - End A: 2/0 ASCR, 2/0 Str., 3/0 Str. Compact, Red, End B: 2 ASCR, 1-2 Str., 1 Str. Compact, Red, Die: 840. For AL to AL and AL to CU Conductors.

Modified Industry Description

COMPRSLEEVE

AD Description

Blackburn® KL45-1 KL Series Non-Insulated Service Entrance Splice, 2 to 3/0 AWG ACSR/Compact/Stranded Conductor, Die Code: 840, 3-1/2 in L, Aluminum

Vendor Description

Blackburn® stands for quality and reliability as a supplier of materials to connect overhead distribution power lines and equipment.

Specifications

Application
Splices Large Conductors For Commercial Service, use as a Low-Cost Reducing Sleeve.
Brand Name
Thomas & Betts
Color
Red
Conductor Range
Wire Range - End A: 2/0 ASCR, 2/0 Stranded, 3/0 Stranded Compact, Red, End B: 2 ASCR, 1-2 Stranded, 1 Stranded Compact, Red
Connection
Compression
Conductor Size
2 to 3/0
Country of Origin
MX
Environmental_Conditions
All Seasons / Conditions
Insulation
None
Material
Aluminum
Mounting
None
Special Features

  • 2/0 AWG ACSR, 2/0 AWG stranded, 3/0 AWG stranded compact end A and 2 AWG ACSR, 2 to 1 AWG stranded, 1 AWG stranded compact end B conductor
  • 840 die series, 840, U-K840 U-249, B49EA hydraulic dies, 840, W-K840 EEI-11A and TX mechanical dies
  • All seasons environmental conditions
  • All sizes can be installed with popular mechanical and hydraulic tools
  • Center stop assures proper conductor positioning
  • Color coded and marked for easy identification
  • Quick identification with Color coded foil caps
  • Splices large conductors required for commercial service, use as low cost reducing sleeve
Standard
Passes the requirements of ANSI C119.4
Sub_Brand
Blackburn
Type
Non-Insulated
Width_2
11.0000
Width_3
21.0000
