SolaHD SolaHD IC115
SolaHD IC115
Kirby Risk #: 545669
UPC: 63391407089, 633914070892, 633914007089, 00633914070892
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: SolaHD
Description
Industry Description
Islatrol Active Tracking Filter, MCOV: 120 Volts/150 VRMS, 240 Volts/275 VRMS, Frequency: 47-63 HZ, Peak Surge Current Capability: 15,000 Amps, Category A Ringwave(6kV, 200 A, 100 kHz): Normal 0.7/0.7, Common 304/306
Modified Industry Description
ISLATRL+ 1PH 15A 120V
Specifications
| Amperage Rating |
15
|
|---|---|
| Brand Name |
SolaHD
|
| Connection |
Barrier strip at input and output/with wire leads at input and output
|
| Country of Origin |
MX
|
| Environmental_Conditions |
-40 to 45 deg C Operating Temperature/0 to 95% Humidity
|
| Frequency_Rating |
47-63
|
| Material |
Plastic
|
| Mounting |
Flange Dimensions: 6.75 x 3.50 x 7.75 x 0.19
|
| Operating_Temperature |
-40°C to +45°C at Full Load; Derate Linearly to 60% at +70ºC
|
| Phase |
1
|
| Response_Time |
<0.5 ns Normal Mode/< 5 ns Common Mode
|
| Short_Circuit_Rating |
Surge current capacity -- 45,000 Amps
|
| Size |
6.25 Length x 4.75 Width x 2.35 High
|
| Special Features |
|
| Standard |
UL 1283, CSA Recognized
|
| Sub_Brand |
SolaHD
|
| Type_Of_Indicators |
LED Power Indicators
|
| Type |
Islatrol IC+ Series
|
| Voltage Rating |
212.132//120
|
