Burndy Burndy QPX4434

Name: Burndy QPX4434
Brand: Burndy
SKU: 539349
Price: 646.75 USD
Availability: InStock

Burndy QPX4434

Kirby Risk #: 539349

UPC: 78181034550, 781810345504, 00781810345504

Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)

Brand: Burndy

Description

Industry Description

Parallel Clamp, Copper: 500-1000 kcmil (Run)/ 250-500 kcmil (Tap).

AD Description

BURNDY® VERSITAP™ QPX4434 Parallel Clamp, 500 to 1000 kcmil Solid/Stranded Copper Conductor, 3/8 in, Copper Alloy

Application	For Tee, Cross, Parallel, Butt And Tap Connections
Country of Origin	US
Length1	2.0600
Material	Copper
Special Features	240 in-lb installation torque Code:250 to 500 kcmil, copperweld to copper:4/0 EK, copperweld:19 to 9 to 19 to 6 AWG tap/secondary conductor range Copperweld:19 to 6 AWG, Code:500 to 1000 kcmil main/primary conductor range Edges are rounded for easy taping, made of high strength, high-conductivity copper alloy and silicon bronze durium hardware Run:copperweld - copper, copperweld, commercial stranded copper, tap:copperweld - copper, copperweld, commercial stranded copper conductors type The versitap type qpx is recommended for tee, cross, parallel, butt and tap connections, range-taking, only 10 connectors required to accommodate conductor sizes from 6 AWG stranded to 1000 kcmil
Standard	UL486C
Sub_Brand	VERSITAP
Temperature_Rating	194
Type	QPX
