Crouse-Hinds Crouse-Hinds EYS716


Description

Industry Description

2 1/2 NPT THRU MALE/FEMALE CST IRON VERT/HORZ SEAL FTG

Modified Industry Description

2 INCH VERT / HORZ Explosionproof Conduit Seal

AD Description

Crouse-Hinds EYS716 Female Hub Conduit Sealing Fitting, 2-1/2 in, For Use With Vertical/Horizontal Positions, Copper Free Aluminum, Natural

Vendor Description

EATON's Crouse-Hinds series is designed to the highest standard of safety and productivity to keep people safe and plants running reliably. The more demanding the environment, the likelier you are to find EATON products at the center of operations.

Specifications

Application
Conduit System
Brand Name
Crouse-Hinds
Connection
Female Threaded, Female Threaded
Country of Origin
US
Enclosure
Class I Div 1 2 Group C D, Class II Div 1 2 Group E F G, Class III
Finish
Natural
Material
Copper Free Aluminum
Special Features

  • 2-11/16 in turning radius
  • 25-1/2 cu-in for vertical position
  • 30 cu-in for horizontal position
  • Integral bushings in conduit hubs to protect conductor insulation from damage
  • Large openings with threaded closures to provide easy access to conduit hubs for making dams
  • Limit explosions to the sealed OFF enclosure
  • Minimum turning radius
  • Restrict the passage of gases, vapors or flames from one portion of the electrical installation to another at atmospheric pressure and normal ambient temperatures
  • Taper-tapped hubs to ensure ground continuity
Standard
UL 886, CSA C22.2
Sub_Brand
Eaton Crouse-Hinds
Type
Female Hub
Width_2
4.0000
