Hoffman Hoffman Q1PBPCD
Hoffman Q1PBPCD
Kirby Risk #: 490886
UPC: 78351015089, 783510150891, 00783510150891
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Hoffman
Description
Industry Description
QLine D Pushbutton, Type 4X, 1PB x 30.5mm, Polycarbonate
Modified Industry Description
30.5 MM PUSHBUTTON ENCLOSURE, 1 HOLE, QLINE POLYCARBONATE AND ABS TYPE 4X, 75 X 73 X 79 MM
AD Description
Hoffman QLINE™ D Q1PBPCD Q41 Pushbutton Enclosure, 3.23 in L x 3.15 in W x 3.11 in D, 1 Outlet, NEMA 4X/IP67 NEMA Rating, Polycarbonate
Vendor Description
Used for insulating and housing 30.5-mm or 22.5-mm pushbuttons in hostile environments, QLine D Enclosures have contoured bodies with flush cover screws for an attractive, contemporary appearance.
Specifications
| Application |
Controls and Drives; Corrosive Environments
|
|---|---|
| Brand Name |
Hoffman
|
| Color |
Light Gray
|
| Country of Origin |
EE
|
| Cover_Type |
Screw
|
| Material |
Polycarbonate
|
| NEMA_Rating |
NEMA 4X/IP67
|
| Number_Of_Holes |
1
|
| Series |
Q41
|
| Size |
3.23 X 3.15 in
|
| Special Features |
|
| Standard |
UL 508A Listed, Type 4, 4X, 12, 13, No. E61997, cUL Listed per CSA C22.2 No 94, Type 4, 4X, 12, 13, No. E61997, Enclosure flammability evaluated per UL 508A, NEMA/EEMAC Type 4, 4X, 12, CSA File Number 42186: Type 4, 4X, 12, IEC 60529, IP67
|
| Sub_Brand |
Hoffman
|
| Type |
Fiberglass and Thermoplastic Industrial Terminal and Junction Boxes
|
