Thomas & Betts Thomas & Betts MS248B


Description

Industry Description

Male screw terminal insert. For use with B series, 48 contacts with ground.

Modified Industry Description

MALE SCREW TERMINAL INSERT B SERIES 48 CONTACTS WITH GRD

AD Description

Pos-E-Kon® MS248B B Series Standard Terminal Insert, 48 Positions, 20 to 14 AWG Wire, Male Screw Connection, Glass Filled Thermoplastic

Vendor Description

Pos-E-Kon® DIN-standard rectangular pin and sleeve connectors are modular for easy assembly at the customer site.

Specifications

Amperage Rating
16Amp
Brand Name
Thomas & Betts
Conductor Size
20-14 AWG
Country of Origin
DE
Material
Glass Filled Thermoplastic
Special Features

  • 48 contacts with ground
  • Allows single access direction panel build wiring and easy terminal ID for service and testing
  • Integral screw terminal contacts that provide for easy terminal wiring and fast assembly
  • Standard size screw terminal
  • Standard wire protection saddles prevent cutting of strands during assembly
  • Use small blade screwdriver to push wire entry tab in for easy contact removal
Sub_Brand
Pos-E-Kon
Temperature_Rating
-40 to 257
Type
Standard
Voltage Rating
600
