O-Z/Gedney O-Z/Gedney X100
O-Z/Gedney X100
Kirby Risk #: 3617720
UPC: 78312657120, 783126571202, 00783126571202
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: O-Z/Gedney
Specifications
| Application |
For Rigid Conduit And IMC
|
|---|---|
| Connection |
Tapered FNPT
|
| Country of Origin |
MX
|
| Finish |
Aluminum
|
| Length1 |
7-1/8
|
| Material |
Malleable
|
| Special Features |
Serve as pulling fittings; Make bends in conduit system; Provide openings for splicing; Connect and change direction of conduit runs; Allow connections for branch runs; Permit access to conductors for maintenance; Tapered threaded hubs (NPT); Raintight when used with gasketed covers; Malleable iron suitable for use in concrete; Internal volume and maximum wire capacity clearly marked on castings; Complete interchangeability with other manufacturers style 5 or 35 conduit bodies; Suitable for wet locations when used with gasketed covers
|
| Standard |
Third Party Certification: UL File Number E-18095, CSA LR-9795, Applicable Third Party Standards: UL 514A, CSA C22.2 No.18, Federal Specification Number A-A-50563, Hazardous Locations: Class 1, Division 2 Per NEC Section 501-4(B), NEMA : FB-1, FB-2.10
|
| Sub_Brand |
Spec 5
|
| Type |
X Conduit Body
|
