GE Industrial 9T58K2813

Industry Description

Core and coil transformers for machine tool applications are used to provide voltage to control devices in applications where regulation and minimum space are important. Fully encapsulated coil is impervious to moisture-Pressure plate terminals ensure secure connections-Terminal board is anchored in the epoxy for greater reliability-Wide variety of fusing options-Rugged, high-impact plastic terminal board-Full head 8 brass screws assure quick, easy terminations with maximum connection integrity-Copper windings -Flexible design allows inp ut or ou tput volta ge to ma tch a ny app lication-CUL, CE, UL approvals-Available fuse-clips offer simple, low-cost fusing with terminal block models and minimum space are important. 58K2813

AD Description

GE GE Industrial Solutions 9T58K2813 Core/Coil Dry Encapsulated Power Transformer, 240/480 VAC Primary, 120/240 VAC Secondary, 1.5 kVA Power Rating, 60 Hz, 1 Phase

Vendor Description

Type IP transformers are core and coil units designed for machine tool, industrial control, panelboard and general purpose applications. These designs are now welded core and encapsulated to provide the highest quality electrical performance. The transformer coil is completely surrounded by epoxy, making the unit impervious to external elements. The lamination core is welded to provide superior quiet performance.
