Hubbell Hubbell HBL26W47
Hubbell HBL26W47
Kirby Risk #: 3140090
UPC: 78358513138, 783585131382, 00783585131382
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Hubbell
Description
Industry Description
Hubbell Wiring Device Kellems, Locking Devices, TwistLock, Elastogrip,Male Plug, 20A 125V, 2-Pole 3-Wire Grounding, L5-20P, Screw Terminal,Yellow, Water/Dust-Tight Housing
Modified Industry Description
PLUG, NEMA L5-20P, 20A 125V, YL
AD Description
Wiring Device-Kellems Twist-Lock® HBL26W47 Non-Shrouded Watertight Locking Plug, 125 VAC, 20 A, 2 Poles, 3 Wires, Yellow
Specifications
| Amperage Rating |
20
|
|---|---|
| Application |
Industrial/Commercial
|
| Brand Name |
Hubbell
|
| Color |
Yellow
|
| Connection |
Screw Terminals
|
| Conductor Size |
#14AWG to #12AWG
|
| Cord_Type |
All Portable
|
| Country of Origin |
CN
|
| Enclosure |
NEMA 4/4X/12/6/6P/IP65/IP66/IP67
|
| Environmental_Conditions |
Watertight
|
| Grade |
Industrial
|
| Material |
Elastomeric/Composite
|
| Mounting |
Cord Mounted
|
| NEMA_Rating |
NEMA L5-20P
|
| Number_Of_Poles |
2
|
| Number_Of_Wires |
3
|
| Phase |
1
|
| Size |
Standard Sized
|
| Special Features |
|
| Standard |
UL498
|
| Sub_Brand |
Twist-Lock
|
| Temperature_Rating |
-40 to 60
|
| Type |
Elastomeric
|
| Voltage Rating |
125
|
