Hubbell Hubbell GFBFST20W
Hubbell GFBFST20W
Kirby Risk #: 3134758
UPC: 88377812223, 883778122231, 00883778122231
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Hubbell
Description
Industry Description
Hubbell Wiring Device Kellems, Power Protection Devices, Self TestFaceless GFCI, 20A 125V, 2-Pole 3-Wire Grounding, White
Modified Industry Description
20A 125V WHITE SELF TEST FACELESS GFCI RECEPTACLE
AD Description
Wiring Device-Kellems AUTOGUARD® Style Line® GFBFST20W Blank Face Heavy Duty Standard Self Test GFCI Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, White
Vendor Description
Hubbell AUTOGUARD® GFR products continually test and monitor for "people protection capability" automatically. This patented safety feature includes disconnecting power to the receptacle if critical components are damaged and GFCI protection is lost. Also, visual indicators are clearly provided on the device face representing "power status", "trip condition", "ground fault condition" and "end of life status".
Specifications
| Amperage Rating |
20
|
|---|---|
| Application |
Commercial Grade
|
| Brand Name |
Hubbell
|
| Color |
White
|
| Connection |
Back and Side Wired Terminal Screws
|
| Conductor Size |
#14 AWG to #12 AWG
|
| Country of Origin |
CN
|
| Environmental_Conditions |
Indoor Dry unless Protected by Additional Means
|
| Material |
Thermoplastic
|
| Mounting |
Screw Mount
|
| Number_Of_Poles |
2-Pole
|
| Number_Of_Wires |
3
|
| Phase |
Single Phase
|
| Size |
Standard Sized Product
|
| Special Features |
|
| Standard |
UL498, UL943
|
| Sub_Brand |
Straight Blade GFCI Receptacles
|
| Type |
Commercial Grade Faceless
|
| Voltage Rating |
125
|
| Wattage |
2500
|
