Hubbell Hubbell HBL24W49
Hubbell HBL24W49
Kirby Risk #: 3109651
UPC: 78358513125, 783585131252, 00783585131252
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Hubbell
Description
Industry Description
Hubbell Wiring Device Kellems, Locking Devices, TwistLock, Elastogrip,Male Plug, 15A 250V, 2-Pole 3-Wire Grounding, L6-15P, Screw Terminal,Yellow, Water/Dust-Tight Housing
Modified Industry Description
15A 250V MALE YELLOW WATER/DUST TIGHT
AD Description
Wiring Device-Kellems Twist-Lock® HBL24W49 Grounding Locking Plug, 250 VAC, 15 A, 2 Poles, 3 Wires, Yellow
Specifications
| Amperage Rating |
15
|
|---|---|
| Application |
Industrial/Commercial
|
| Brand Name |
Hubbell
|
| Color |
Yellow
|
| Connection |
Screw Terminals
|
| Conductor Size |
16/3 SJ to 10/3 SJ, 18/3 S to 12/3 S
|
| Cord_Type |
All Portable
|
| Country of Origin |
US
|
| Dimensions |
1.85 in Dia x 3.21 in L
|
| Enclosure |
NEMA 4/4X/6/6P/12
|
| Environmental_Conditions |
Watertight
|
| Grade |
Commercial/Industrial
|
| Horsepower |
1-1/2
|
| Length1 |
9.0000
|
| Material |
Elastomeric/Composite
|
| Mounting |
Cord Mounted
|
| NEMA_Rating |
L6-15P
|
| Number_Of_Poles |
2
|
| Number_Of_Wires |
3
|
| Phase |
Single
|
| Size |
Standard Sized
|
| Special Features |
|
| Standard |
UL498
|
| Sub_Brand |
Hubbell Wiring Device-Kellems
|
| Temperature_Rating |
-40 to 60
|
| Type |
Grounding
|
| Voltage Rating |
250
|
