Hubbell Hubbell L1530R
Hubbell L1530R
Kirby Risk #: 2919983
UPC: 78358584067, 783585840673, 00783585840673, 30783585840674
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Hubbell
Description
Industry Description
Hubbell Wiring Device Kellems, Locking Devices, SELECT SPEC TwistLock,Commercial/Industrial, Flush Receptacle, 30A 3-Phase Delta 250V AC, 3-Pole 4-Wire Grounding, L15-30R, Screw Terminal, Black
Modified Industry Description
30A 250V RECPT BLACK
AD Description
Wiring Device-Kellems Select Spec™ Twist-Lock® L1530R 3-Phase Grounding Standard Single Locking Receptacle, 250 VAC, 30 A, 3 Poles, 4 Wires, Black
Specifications
| Amperage Rating |
30
|
|---|---|
| Application |
Heavy Duty- Select Spec
|
| Color |
Black
|
| Connection |
Screw Terminals
|
| Conductor Size |
#10 AWG
|
| Country of Origin |
US
|
| Environmental_Conditions |
Indoor Dry unless Protected by Additional Means
|
| Length1 |
4.5000
|
| Material |
Thermoplastic
|
| Mounting |
Screw Mount
|
| NEMA_Rating |
L15-30R
|
| Number_Of_Poles |
3
|
| Phase |
3
|
| Size |
Standard Sized Product
|
| Special Features |
|
| Standard |
NEMA WD1 and WD5, UL 498
|
| Sub_Brand |
Hubbell Wiring Device-Kellems
|
| Type |
Single Receptacle
|
| Voltage Rating |
250
|
| Wattage |
7.5k
|
