Hubbell Hubbell HBL7882D
Hubbell HBL7882D
Kirby Risk #: 2918539
UPC: 78358520292, 783585202921, 00783585202921, 30783585202922
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Hubbell
Description
Industry Description
Hubbell Wiring Device Kellems, Switches and Lighting Controls,Industrial Grade, Manual Motor Controllers, Motor Disconnects, Two Pole,80A 600V AC, Back and Side Wired
Modified Industry Description
85A 600V 2P DISC SW
AD Description
Wiring Device-Kellems Circuit-Lock® HBL7882D Standard AC Motor Disconnect Switch, 600 VAC, 85 A, 20 hp, 2 Poles
Specifications
| Amperage Rating |
85
|
|---|---|
| Application |
Motor Starting w/o Overload Protection
|
| Connection |
Pressure Screw Terminals
|
| Country of Origin |
PR
|
| Enclosure |
None
|
| Environmental_Conditions |
Indoor Dry unless Protected by Additional Means
|
| Length1 |
3.7980
|
| Material |
Stainless Steel
|
| Mounting |
Screw Mount
|
| Number_Of_Poles |
2
|
| Operating_Temperature |
Minimum Continuous -40 Deg C without Impact
|
| Phase |
1
|
| Power_Rating |
51000
|
| Series |
Standard Toggle
|
| Size |
Standard Sized Product
|
| Special Features |
|
| Standard |
UL508
|
| Sub_Brand |
Hubbell Wiring Device-Kellems
|
| Temperature_Rating |
Minimum Continuous -40 Deg C without Impact
|
| Type |
Open Switch
|
| Voltage Rating |
600
|
| Wattage |
51000
|
