Crouse-Hinds Crouse-Hinds EYSR8


Description

Industry Description

3 RETROFIT SEALING FITTING 8 1/2 X 5 1/2 X 4 1/4

Modified Industry Description

3 RETROFIT SEALING FTG 8 1/2 X 5

AD Description

Crouse-Hinds Condulet® EYSR8 Dust-Ignitionproof Explosionproof Retrofit Sealing Fitting, 3 in NPT, For Use With Vertical/Horizontal Positions Rigid Conduit System, Feraloy® Iron Alloy, Electro-Galvanized

Specifications

Application
Rigid Metal Conduit
Construction
Explosionproof, Dust Ignitionproof
Country of Origin
US
Dimensions
5-1/2 in H x 8-1/2 in W x 4-1/4 in D
Enclosure
Class I Div 1 2 Group C D, Class II Div 1 2 Group E F G
Finish
Electro-Galvanized
Length1
8.5000
Material
Feraloy® Iron Alloy
Mounting_Type
Surface
Series
EYSR
Size
3 in NPT
Special Features

  • Neoprene gasket
  • Overall length and spacing requirements do not exceed those of standard EYS seals, permits close nesting of seals
  • Pipe plugs permit the installation of a standard ECD15 drain fitting (order separately) for use in vertical conduit runs to drain any water that might accumulate in the conduit system
  • Seal may be installed in the existing conduit RUN without disassembly of the conduit system, saving time and labor
  • Steel pipe plugs, bolts and set-screws
  • Steel set-screws provide grounding continuity
  • To limit explosions to the sealed OFF enclosure
  • To limit pre-compression or "pressure piling" in the conduit system
  • To prevent accumulation of water in the conduit when installed with a drain
  • To restrict the passage of gases, vapors or flames from one portion of the electrical system to another
Standard
UL 886, CSA C22.2
Sub_Brand
Eaton Crouse-Hinds
Type
Dust-Ignitionproof Explosionproof
