GE Industrial 9T51B1815
9T51B1815
Kirby Risk #: 2385621
UPC: 78317314947, 783173149478, 00783173149478
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Description
Industry Description
These GE transformers feature an encapsulated core and coil in a NEMA 3R non-ventilated weatherproof enclosure. UL Listed-C-UL Listed-Knockouts provided on back and bottom-High grade silicon steel core-Mounting holes on side for easy access- Wiring compartment includes ground stud 51B1815
AD Description
GE 9T51B1815 Type QB Dry Encapsulated Enclosed Standard General Purpose Transformer, 208/240 VAC Primary, 120 VAC Secondary, 3 kVA, 60 Hz, 1 Phase
Specifications
| Application |
Electrical distribution and Control
|
|---|---|
| Country of Origin |
UKN
|
| Enclosure |
NEMA 3R
|
| Insulation |
IS-12
|
| Length1 |
12.5000
|
| Phase |
1
|
| Special Features |
|
| Standard |
True
|
| Sub_Brand |
GE Industrial Solution
|
| Type |
Transformers
|
| Wattage |
3
|
