Panduit Panduit H000X034H2C


Description

Industry Description

The portable printer continuous heat shrink labels in yellow are made of military-grade polyolefin. They measure 0.19" (4.6mm) diameter, 8' (2.4m) length, and 0.34" (8.6mm) width and have a wire range of 18–12 AWG. The fast-loading P1™ label cassette includes both label material and ribbon for easy label changing.

Modified Industry Description

3/16 IN YELLOW 18 - 12 AWG P1 CASSETTE LABELS

AD Description

Panduit® P1™ H000X034H2C Continuous Military Grade Heat Shrink Label Cassette, 18 to 12 AWG, Yellow Marker, Polyolefin

Specifications

Brand Name
Panduit
Color
Yellow
Country of Origin
CRI
Material
Polyolefin
Package_Quantity
1
Shrink_Ratio
3:1
Special Features

  • Each cassette contains a continuous roll of non-adhesive flattened polyolefin that can be cut-to-length
  • Fast loading label cassette includes both label material and ribbon to make changing labels easy
  • P1™ Label Cassette contains an integrated memory device for automatic formatting, recall of last legend used, and number of labels remaining in the cassette
  • Shrink ratio 3:1
  • Use with PanTher™ LS8E or Cougar™ LS9 hand-held thermal transfer printers
Standard
MIL-M-81531 and MIL-STD-202G Method 215K, Solution A, C, and D. UL Standard 224 for flammability.
Sub_Brand
Panduit
Temperature_Range
275
Type
Continuous Military Grade
Width_2
6.2000
Width_3
6.2500
