Siemens Siemens LXD62B600L
Siemens LXD62B600L
Kirby Risk #: 2292941
UPC: 78364301113, 783643011137, 00783643011137
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Siemens
Description
Industry Description
SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. ASSEMBLED STANDARD 40 DEG C BREAKER LD FRAME WITH STANDARD BREAKING CAPACITY. 600A 2-POLE (25KAIC AT 600V) (35KAIC AT 480V). NON-INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES LINE AND LOAD SIDE LUGS (TA2J6500) WIRE RANGE 3/0AWG - 500KCMIL (CU) / 4/0AWG - 500KCMIL (AL). DIMENSIONS (W x H x D) IN 7.50 x 11.0 x 4.00.
AD Description
Sentron™ LXD62B600L Molded Case Circuit Breaker, 600 VAC, 600 A, 25 kA Interrupt, 2 Poles, Thermal Magnetic Trip
Vendor Description
SiemensSentronSeriesCircuit Breakers have a long history of excellent performance in both the commercial and industrial market segments, they are tried and true in the most critical applications. Siemens SentronSeries circuit breakers are available in nine frame sizes from 125 to 2000 A.
Specifications
| Actuator |
Varying
|
|---|---|
| Amperage Rating |
600
|
| Application |
Standard 40C Breaker
|
| Connection |
Line/Load lugs installed
|
| Country of Origin |
MX
|
| Dimensions |
7 in L x 9 in W x 13 in H
|
| Enclosure |
Varying
|
| Environmental_Conditions |
N/A
|
| Frame |
LD
|
| Frequency_Rating |
50/60
|
| Interrupt_Rating |
25
|
| Length1 |
13.0000
|
| Material |
N/A
|
| Number_Of_Poles |
2
|
| Operating_Temperature |
40C
|
| Special Features |
|
| Standard |
UL/HACR
|
| Sub_Brand |
SENTRON
|
| Temperature_Rating |
40
|
| Type |
LXD6
|
| Voltage Rating |
600
|
