Leviton Leviton 61110-RY6


Description

Industry Description

eXtreme 6+ QuickPort Connector, CAT 6, Yellow

Modified Industry Description

1 PORT QuickPort CAT 6+ 25 PACK YELLOW

AD Description

Leviton® eXtreme® QuickPort® 61110-RY6 8-Conductor 8-Position Channel/Component Rated UTP Connector, Cat 6+ Module, Panel/Surface Mount, 1 Port, Plastic, Yellow

Specifications

Application
Commercial
Brand Name
Leviton
Color
Yellow
Country of Origin
US
Environmental_Conditions
Flammability (Rated V-0 Per UL94)
Material
Plastic
Mounting
Wallplate, Panel
Number_Of_Ports
1
Size
0.89 H X 0.64 W X 1.21 D
Special Features

  • 180 deg configuration allows for rear termination
  • Capable of multiple re-termination
  • Dual layer T568B/T568A wiring label simplifies punchdown
  • Fire retardant
  • Gastight IDC connectors prevent corrosion
  • High quality copper based alloy plated with 50 micro-in of gold over 100 micro-in of nickel
  • Pair separation tower design facilitates separation of conductors and minimizes untwisting
  • Patented retention force technology (RFT) protects tines from damage and increases system longevity
  • Permanently laser engraved
  • Terminates 26 to 22 AWG solid conductor
  • Unique pair separation tower (PST) allowing for quick and easier termination
Standard
ANSI\TIA-568-C.2;ISO\IEC 11801 Class E;cULus Listed;ANSI\TIA-1096-A (Formerly FCC Part 68);CSA Certified;FCC Part 68 Compliant;NEC Article 800 Compliant;
Sub_Brand
Leviton
Type
CAT 6+ Quickport Connector
Width_2
5.5000
