Hubbell Hubbell HBL1282
Hubbell HBL1282
Kirby Risk #: 2174407
UPC: 78358501685, 783585016856, 00783585016856
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Hubbell
Description
Industry Description
Hubbell Wiring Device Kellems, Switches and Lighting Controls,Industrial Grade, PresSwitch, General Purpose AC, Double Pole, 20A120/277V AC, Screw Terminals, Brown
Modified Industry Description
PresSwitch Series, Single Pole,
AD Description
Wiring Device-Kellems PresSwitch® HBL1282 General Purpose Heavy Duty Standard Pushbutton Switch, 120/277 VAC, 20 A, 5540 W Power Rating, 2-Position Contact
Specifications
| Action |
Snap
|
|---|---|
| Actuator |
Push Button
|
| Amperage Rating |
20
|
| Application |
Heavy Duty Industrial
|
| Brand Name |
Hubbell
|
| Color |
Brown
|
| Connection |
Terminal Screws
|
| Contact_Configuration |
Two Position
|
| Country of Origin |
PR
|
| Environmental_Conditions |
Indoor Dry unless Protected by Additional Means
|
| Mounting |
Mounting Screws
|
| Number_Of_Poles |
2
|
| Operating_Cycles |
10k
|
| Operating_Temperature |
Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
|
| Size |
Standard Sized
|
| Special Features |
|
| Standard |
UL 20
|
| Sub_Brand |
Hubbell Wiring Device-Kellems
|
| Type |
PresSwitches
|
| Voltage Rating |
120/277
|
| Wattage |
5,540
|
