Leeson Leeson 131549.00
Leeson 131549.00
Kirby Risk #: 2108682
UPC: 69172001796
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Leeson
Description
Modified Industry Description
5HP..3500RPM.184.TEFC./230V.1PH.60H
AD Description
LEESON® 131549 Type KF Continuous Duty AC Motor, 5 hp, 230 VAC, 60 Hz, 1 ph, 180 Frame, 3500 rpm, Rigid Mount, Totally Enclosed Fan Cooled (TEFC) Enclosure
Specifications
| Amperage Rating |
23
|
|---|---|
| Application |
For use where water and dust exposure is minimal. Ideally suited for use on pumps, compressors, blowers, fans and other standard industrial applications.
|
| Bearing_Type |
BALL
|
| Brand Name |
Leeson
|
| Efficiency |
82.5
|
| Enclosure |
TEFC
|
| Frame |
180
|
| Frequency_Rating |
60
|
| Horsepower |
5
|
| Insulation_Class |
Class F
|
| Mounting |
Rigid
|
| Phase |
1
|
| Power_Rating |
3.73
|
| Rotation |
Selective Counter Clockwise
|
| RPM |
3500
|
| Service_Factor |
1.1499999999999999
|
| Shaft_Size |
1-1/8 in Dia
|
| Special Features |
|
| Type |
Type KF Continuous Duty
|
| Voltage Rating |
230
|
