Hubbell Hubbell HBL7842D

Name: Hubbell HBL7842D
Brand: Hubbell
SKU: 2040600
Price: 174.94 USD
Availability: InStock

Hubbell HBL7842D

Kirby Risk #: 2040600

UPC: 78358520284, 783585202846, 00783585202846

Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)

Brand: Hubbell

Description

Industry Description

Hubbell Wiring Device Kellems, Switches and Lighting Control, MotorDisconnect, 2-Pole, 40A 600V, Back and Side Wired, Short Toggle

Modified Industry Description

40A 600V - DISCONNECT SWITCH, 2 POLE

AD Description

Wiring Device-Kellems Circuit-Lock® HBL7842D Standard AC Motor Disconnect Switch, 600 VAC, 40 A, 2 Poles

Amperage Rating	40
Application	Motor Starting w/o Overload Protection
Brand Name	Hubbell
Connection	Pressure Screw Terminals
Country of Origin	US
Enclosure	None
Environmental_Conditions	Indoor Dry unless Protected by Additional Means
Material	Stainless Steel
Mounting	Screw Mount
Number_Of_Poles	2
Operating_Cycles	10k
Operating_Temperature	Minimum Continuous -40 Deg C without Impact
Phase	1
Size	Standard Sized Product
Special Features	2 hp at 120 VAC, 5 hp at 240 VAC, 10 hp at 480 VAC, 15 hp at 600 VAC power rating at 1-phase Clamping plate for secure back or side wiring Excellent dimensional stability and superior dielectric strength For close wall applications and finger safe environment Provides high resistance to electrical arc tracking Provides long life reliability Strong ON/OFF action with quick make, slow break operation Switches and lighting controls, industrial grade, disconnect switches Withstands high temperatures
Standard	UL508
Sub_Brand	Hubbell Wiring Device-Kellems
Type	Open Switch
Voltage Rating	600
Width_2	4.0480
Width_3	13.1250
Width_4	13.1250
